1) Machine Size(L*W*H):1100*780*1200±30mm
2) Special Aluminum alloy guide rails and rubber belt
3) Magazine lifting with screw rod by 90W electric-brake motor which made in Taiwan
4) Transport motor used 15W stable speed motor made in Taiwan
5) Pneumatic PCB clamping structure
6) Magazine size(L*W*H): 355*320*565mm
7) PCB size(L*W):330*250mm
8) Direction:R-L/L-R
9) Adjustable Lifting distance:10,20,30,and 40mm
10) Transport high: 920±30mm
11) Programmable Mitsubishi PLC and controller
12) PCB Automatic loading to conveyor
13) Operation Control system: Touch Panel controlled interface
14) Pneumatic Compone(Push plate cylinder with a screw adjustment positionnt)
15) Power: 220V 50HZ
16) Air pressure: 0.4-0.6MPa
17) the max store PCB Quantity:50pcs
18) One set Electronic control box
